GA-H310TN
- 中央處理器(CPU): Support for 9th and 8th Generation Intel | ® | Core™ i9 processors/Intel | ® | Core™ i7 processors/Intel | ® | Core™ i5 processors/Intel | ® | Core™ i3 processors/Intel | ® | Pentium | ® | processors/Intel | ® | Celeron | ® | processors in the LGA1151 package | | L3 cache varies with CPU | | (Please refer "CPU Support List" for more information.)
- 晶片組: Intel | ® | H310 Express Chipset
- 記憶體: 1 x DDR4 SO-DIMM sockets supporting up to 16 GB of system memory | | Support for DDR4 2400/2133 MHz memory modules | | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | | (Please refer "Memory Support List" for more information.)
- 顯示功能: Integrated Graphics Processor-Intel | ® | HD Graphics support | | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | | 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz | * Support for HDMI 1.4 version and HDCP 2.2. | | Maximum shared memory of 1 GB
- 音效: Realtek | ® | ALC887 codec | | High Definition Audio | | 2/4/5.1/7.1-channel
- 網路: Realtek | ® | GbE LAN chips (10/100/1000 Mbit)
- TPM: Infineon chip, supporting TPM 2.0
- 擴充槽: 1 x M.2 Socket 1 connector for an Intel® CNVi wireless module only (CNVI)
- 儲存裝置介面: Chipset: | | 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support) (M2A) | | 2 x SATA 6Gb/s connectors
- USB: Chipset: | | 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header) | | 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 內接插座: 1 x 4-pin ATX 12V power connector | | 1 x CPU fan header | | 1 x system fan header | | 2 x SATA 6Gb/s connectors | | 1 x SATA power connector | | 1 x front panel header | | 1 x front panel audio header | | 1 x battery power cable connector | | 1 x USB 3.0/2.0 header | | 1 x USB 2.0/1.1 header | | 2 x serial port headers | | 1 x LVDS header | | 1 x LVDS drive voltage jumper (LCD_VCC) | | 1 x flat panel display header (FPD) | | 1 x flat panel display power jumper (FPD_PWR) | | 1 x speaker header (SPKR) | | 1 x buzzer header (SPEAKER) | | 1 x Clear CMOS jumper | | 1 x chassis intrusion header
- 後方面板裝置連接插座: 1 x DC-In power connector | | 2 x USB 2.0/1.1 ports | | 2 x USB 3.0/2.0 ports | | 1 x RJ-45 port | | 1 x HDMI port | | 1 x D-Sub port | | 2 x audio jacks
- I/O控制器: iTE | ® | I/O Controller Chip
- 硬體監控: Voltage detection | | Temperature detection | | Fan speed detection | | Overheating warning | | Fan fail warning | | Fan speed control | * Whether the fan speed control function is supported will depend on the cooler you install.
- BIOS: 1 x 128 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for @BIOS | | Support for Q-Flash
- 附贈軟體: Norton | ® | Internet Security (OEM version)
- 作業系統: Support for Windows 10 64-bit
- PCB規格: Thin Mini-ITX Form Factor; 17.0cm x 17.0cm
- Operating Temperature: 0°C to +50°C
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
- 中央處理器(CPU): Support for 9th and 8th Generation Intel | ® | Core™ i9 processors/Intel | ® | Core™ i7 processors/Intel | ® | Core™ i5 processors/Intel | ® | Core™ i3 processors/Intel | ® | Pentium | ® | processors/Intel | ® | Celeron | ® | processors in the LGA1151 package | | L3 cache varies with CPU | | (Please refer "CPU Support List" for more information.)
- 晶片組: Intel | ® | H310 Express Chipset
- 記憶體: 1 x DDR4 SO-DIMM sockets supporting up to 16 GB of system memory | | Support for DDR4 2400/2133 MHz memory modules | | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | | (Please refer "Memory Support List" for more information.)
- 顯示功能: Integrated Graphics Processor-Intel | ® | HD Graphics support | | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | | 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz | * Support for HDMI 1.4 version and HDCP 2.2. | | Maximum shared memory of 1 GB
- 音效: Realtek | ® | ALC887 codec | | High Definition Audio | | 2/4/5.1/7.1-channel
- 網路: Realtek | ® | GbE LAN chips (10/100/1000 Mbit)
- TPM: Infineon chip, supporting TPM 2.0
- 擴充槽: 1 x M.2 Socket 1 connector for an Intel® CNVi wireless module only (CNVI)
- 儲存裝置介面: Chipset: | | 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe x4/x2 SSD support) (M2A) | | 2 x SATA 6Gb/s connectors
- USB: Chipset: | | 4 x USB 3.0/2.0 ports (2 ports on the back panel, 2 ports available through the internal USB header) | | 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 內接插座: 1 x 4-pin ATX 12V power connector | | 1 x CPU fan header | | 1 x system fan header | | 2 x SATA 6Gb/s connectors | | 1 x SATA power connector | | 1 x front panel header | | 1 x front panel audio header | | 1 x battery power cable connector | | 1 x USB 3.0/2.0 header | | 1 x USB 2.0/1.1 header | | 2 x serial port headers | | 1 x LVDS header | | 1 x LVDS drive voltage jumper (LCD_VCC) | | 1 x flat panel display header (FPD) | | 1 x flat panel display power jumper (FPD_PWR) | | 1 x speaker header (SPKR) | | 1 x buzzer header (SPEAKER) | | 1 x Clear CMOS jumper | | 1 x chassis intrusion header
- 後方面板裝置連接插座: 1 x DC-In power connector | | 2 x USB 2.0/1.1 ports | | 2 x USB 3.0/2.0 ports | | 1 x RJ-45 port | | 1 x HDMI port | | 1 x D-Sub port | | 2 x audio jacks
- I/O控制器: iTE | ® | I/O Controller Chip
- 硬體監控: Voltage detection | | Temperature detection | | Fan speed detection | | Overheating warning | | Fan fail warning | | Fan speed control | * Whether the fan speed control function is supported will depend on the cooler you install.
- BIOS: 1 x 128 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for @BIOS | | Support for Q-Flash
- 附贈軟體: Norton | ® | Internet Security (OEM version)
- 作業系統: Support for Windows 10 64-bit
- PCB規格: Thin Mini-ITX Form Factor; 17.0cm x 17.0cm
- Operating Temperature: 0°C to +50°C
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
