GA-IMB1900N
- 中央處理器(CPU): Built in with an Intel | ® | Quad-Core Celeron | ® | J1900 SoC (2.42 GHz) | * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components. | | | 2 MB Cache
- 記憶體: 2 x DDR3L SO-DIMM socket supporting up to 16 GB of system memory | | Dual channel memory architecture | | Support for DDR3L 1066/1333 MHz memory module | | (Please refer "Memory Support List" for more information.)
- 顯示功能: Integrated in the SoC: | | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | | 1 x HDMI port, supporting a maximum resolution of 1920x1200@60 Hz | | Maximum shared memory of 512 MB
- 音效: Realtek | ® | ALC887codec | | High Definition Audio | | 2/4/5-channel
- 網路: 2 x Intel | ® | i211AT GbE LAN chips (10/100/1000 Mbit)
- 擴充槽: 1 x PCI Express x1 slot | | 1 x Mini PCIe slot (MINI_PCIE) | (The PCIe Express x1 and Mini PCIe slots conform to PCI Express 2.0 standard.)
- 儲存裝置介面: Integrated in the SoC: | | 2 x SATA 3Gb/s connectors | | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x1 SSD support) | * The M.2 connector operates at up to x1 mode. | | 1 x mSATA co-lay with mini PCIe
- USB: Integrated in the SoC: | | 4 x USB 3.0 Gen 1 ports on the back panel | | 4 x USB 2.0/1.1 ports available through the internal USB headers
- 內接插座: 1 x 4-pin ATX 12V power connector | | 1 x CPU fan header | | 1 x system fan header | | 2 x SATA 3Gb/s connectors | | 1 x M.2 Socket 3 connector | | 1 x SATA power connector | | 1 x front panel header | | 1 x front panel audio header | | 1 x battery cable header | | 2 x USB 2.0/1.1 headers | | 4 x serial port headers | | 4 x serial port power select jumpers | | 1 x D-Sub header | | 1 x LVDS header | | 1 x LVDS drive voltage jumper (LCD_VCC) | | 1 x flat panel display header (FPD) | | 1 x flat panel display power select jumper (FPD_PWR) | | 1 x flat panel display switch header (MON_SW) | | 1 x backlight switch header (BL_SW) | | 1 x digital microphone header (DMIC_CON) | | 1 x speaker header (SPKR) | | 1 x buzzer header (SPEAKER) | | 1 x chassis intrusion jumper | | 1 x LPT/GPIO header (LPT_GPIO) | | 1 x LPT configuration jumper (LPT_SEL) | | 1 x GPIO power selection jumper (GPIO_PWRSEL) | | 1 x GPIO status configuration jumper (GPIO_SET) | | 1 x BIOS Select jumper (BIOS_SET) | | 1 x Clear CMOS jumper
- 後方面板裝置連接插座: 1 x HDMI port | | 1 x D-Sub port | | 4 x USB 3.0 Gen 1 ports | | 2 x RJ-45 ports | | 2 x audio jacks (Line In, Mic In) | | 2 x Serial ports
- I/O控制器: iTE | ® | I/O Controller Chip
- 硬體監控: Voltage detection | | Temperature detection | | Fan speed detection
- BIOS: 1 x 64 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for Xpress Install | | Support for @BIOS | | Support for APP Center | * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications
- 附贈軟體: Norton | ® | Internet Security (OEM version)
- 作業系統: Support for Windows 7 32/64-bit, Windows 10, LINUX
- PCB規格: Mini-ITX Form Factor; 17.0cm x 17.0cm
- Operating Temperature: 0°C to +60°C
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
