H410M S2 V2
- 中央處理器(CPU): Support for 10th Generation Intel | ® | Core™ i9 processors/Intel | ® | Core™ i7 processors/Intel | ® | Core™ i5 processors/Intel | ® | Core™ i3 processors/Intel | ® | Pentium | ® | processors/Intel | ® | Celeron | ® | processors in the LGA1200 package | | L3 cache varies with CPU | | (Please refer "CPU Support List" for more information.)
- 晶片組: Intel | ® | H470 Express Chipset
- 記憶體: Intel | ® | Core™ i9/i7 processors: | Support for DDR4 2933/2666/2400/2133 MHz memory modules | | Intel | ® | Core™ i5/i3/Pentium | ® | /Celeron | ® | processors: | Support for DDR4 2666/2400/2133 MHz memory modules | | 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory | | Dual channel memory architecture | | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | | Support for Extreme Memory Profile (XMP) memory modules | | (Please refer "Memory Support List" for more information.)
- 顯示功能: Integrated Graphics Processor-Intel | ® | HD Graphics support: | | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | | Maximum shared memory of 512 MB
- 音效: Realtek | ® | Audio CODEC | | High Definition Audio | | 2/4/5.1/7.1-channel | * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
- 網路: Intel | ® | GbE LAN chip (1000/100 Mbit)
- 擴充槽: 1 x PCI Express x16 slot, running at x16 | | 2 x PCI Express x1 slots | (The PCI Express slots conform to PCI Express 3.0 standard.) | | Supports up to ASPM L1.2 power management protocols.
- 儲存裝置介面: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) | | 4 x SATA 6Gb/s connectors | | Support for RAID 0, RAID 1, RAID 5, and RAID 10 | | Intel | ® | Optane™ Memory Ready | | M.2 connectors support up to ASPM L1.2 PCIe power management protocols.
- USB: Chipset: | | 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | | 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- 內接插座: 1 x 24-pin ATX main power connector | | 1 x 8-pin ATX 12V power connector | | 4 x SATA 6Gb/s connectors | | 1 x CPU fan header | | 1 x system fan header | | 1 x RGB LED strip header | | 1 x front panel header | | 1 x front panel audio header | | 1 x USB 3.2 Gen 1 header | | 1 x USB 2.0/1.1 header | | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | | 1 x serial port header | | 1 x Clear CMOS jumper
- 後方面板裝置連接插座: 1 x PS/2 keyboard port | | 1 x PS/2 mouse port | | 1 x D-Sub port | | 2 x USB 3.2 Gen 1 ports | | 4 x USB 2.0/1.1 ports | | 1 x RJ-45 port | | 3 x audio jacks
- I/O控制器: iTE | ® | I/O Controller Chip
- 硬體監控: Voltage detection | | Temperature detection | | Fan speed detection | | Overheating warning | | Fan fail warning | | Fan speed control | * Whether the fan speed control function is supported will depend on the cooler you install.
- BIOS: 1 x 256 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for APP Center | * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | @BIOS | Ambient LED | EasyTune | Fast Boot | Game Boost | ON/OFF Charge | Smart Backup | System Information Viewer | | Support for Q-Flash | | Support for Xpress Install
- 附贈軟體: Norton | ® | Internet Security (OEM version) | | cFosSpeed
- PCB規格: Micro ATX Form Factor; 22.6cm x 18.5cm
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
- 中央處理器(CPU): Support for 10th Generation Intel | ® | Core™ i9 processors/Intel | ® | Core™ i7 processors/Intel | ® | Core™ i5 processors/Intel | ® | Core™ i3 processors/Intel | ® | Pentium | ® | processors/Intel | ® | Celeron | ® | processors in the LGA1200 package | | L3 cache varies with CPU | | (Please refer "CPU Support List" for more information.)
- 晶片組: Intel | ® | H470 Express Chipset
- 記憶體: Intel | ® | Core™ i9/i7 processors: | Support for DDR4 2933/2666/2400/2133 MHz memory modules | | Intel | ® | Core™ i5/i3/Pentium | ® | /Celeron | ® | processors: | Support for DDR4 2666/2400/2133 MHz memory modules | | 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory | | Dual channel memory architecture | | Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) | | Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | | Support for Extreme Memory Profile (XMP) memory modules | | (Please refer "Memory Support List" for more information.)
- 顯示功能: Integrated Graphics Processor-Intel | ® | HD Graphics support: | | 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz | | Maximum shared memory of 512 MB
- 音效: Realtek | ® | Audio CODEC | | High Definition Audio | | 2/4/5.1/7.1-channel | * To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
- 網路: Intel | ® | GbE LAN chip (1000/100 Mbit)
- 擴充槽: 1 x PCI Express x16 slot, running at x16 | | 2 x PCI Express x1 slots | (The PCI Express slots conform to PCI Express 3.0 standard.) | | Supports up to ASPM L1.2 power management protocols.
- 儲存裝置介面: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) | | 4 x SATA 6Gb/s connectors | | Support for RAID 0, RAID 1, RAID 5, and RAID 10 | | Intel | ® | Optane™ Memory Ready | | M.2 connectors support up to ASPM L1.2 PCIe power management protocols.
- USB: Chipset: | | 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | | 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
- 內接插座: 1 x 24-pin ATX main power connector | | 1 x 8-pin ATX 12V power connector | | 4 x SATA 6Gb/s connectors | | 1 x CPU fan header | | 1 x system fan header | | 1 x RGB LED strip header | | 1 x front panel header | | 1 x front panel audio header | | 1 x USB 3.2 Gen 1 header | | 1 x USB 2.0/1.1 header | | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | | 1 x serial port header | | 1 x Clear CMOS jumper
- 後方面板裝置連接插座: 1 x PS/2 keyboard port | | 1 x PS/2 mouse port | | 1 x D-Sub port | | 2 x USB 3.2 Gen 1 ports | | 4 x USB 2.0/1.1 ports | | 1 x RJ-45 port | | 3 x audio jacks
- I/O控制器: iTE | ® | I/O Controller Chip
- 硬體監控: Voltage detection | | Temperature detection | | Fan speed detection | | Overheating warning | | Fan fail warning | | Fan speed control | * Whether the fan speed control function is supported will depend on the cooler you install.
- BIOS: 1 x 256 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for APP Center | * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. | @BIOS | Ambient LED | EasyTune | Fast Boot | Game Boost | ON/OFF Charge | Smart Backup | System Information Viewer | | Support for Q-Flash | | Support for Xpress Install
- 附贈軟體: Norton | ® | Internet Security (OEM version) | | cFosSpeed
- PCB規格: Micro ATX Form Factor; 22.6cm x 18.5cm
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
