ASRock Z790 Lightning WiFi

Lightning series stands as a symbol of both speed and power. The design employs linear and angular elements, evoking the imagery of lightning a spectacle of raw energy and breathtaking speed.

Specifications

• Supports Intel Volume Management Device (VMD)
• Supports NVMe SSD as boot disks
• RAID - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
• - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
• USB - 1 x USB 3.2 Gen2x2 Type-C (Rear)
• - 2 x USB 3.2 Gen2 Type-A (Rear)
• - 1 x USB 3.2 Gen1 Type-C (Front)
• - 8 x USB 3.2 Gen1 Type-A (4 Rear, 4 Front)
• - 3 x USB 2.0 (1 Rear, 2 Front)
• All USB ports support ESD Protection
• Connector - 1 x eDP Signal Connector
• - 1 x Thermistor Cable Header
• - 1 x SPI TPM Header
• - 1 x Power LED and Speaker Header
• - 1 x RGB LED Header*
• - 3 x Addressable LED Headers**
• - 1 x CPU Fan Connector (4-pin)***
• - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
• - 1 x Chassis Fan Connector (4-pin)*****
• - 4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)******
• - 1 x 24 pin ATX Power Connector
• - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector)
• - 1 x Front Panel Audio Connector
• - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card)
• - 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
• - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
• - 1 x Front Panel Type C USB 3.2 Gen1 Header
• Supports in total up to 12V/3A, 36W LED Strip
• Support in total up to 5V/3A, 15W LED Strip
• CPU_FAN1 supports the fan power up to 1A (12W).
• CPU_FAN2/WP supports the fan power up to 2A (24W).
• CHA_FAN5 supports the fan power up to 1A (12W).
• CHA_FAN1~4/WP support the fan power up to 2A (24W).
• CPU_FAN2/WP and CHA_FAN1~4/WP can auto detect if 3-pin or 4-pin fan is in use.
• Rear Panel I/O - 2 x Antenna Ports
• - 1 x PS/2 Mouse/Keyboard Port
• - 1 x HDMI Port
• - 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)
• - 1 x USB 3.2 Gen2x2 Type-C Port (20 Gb/s)
• - 4 x USB 3.2 Gen1 Ports
• - 1 x USB 2.0 Port
• - 1 x RJ-45 LAN Port
• - HD Audio Jacks: Line in / Front Speaker / Microphone
• Software and UEFI **Software**
• - ASRock Motherboard Utility (Phantom Gaming Tuning)
• - Killer Control Center
• - ASRock Polychrome SYNC*
• UEFI**
• - ASRock EZ Mode
• - ASRock Full HD UEFI
• - ASRock My Favorites in UEFI
• - ASRock Auto Driver Installer
• - ASRock Instant Flash
• - ASRock Easy RAID Installer
• These utilities can be downloaded from ASRock Live Update & APP Shop.
• Accessories - 1 x User Manual
• - 2 x SATA Data Cables
• - 2 x ASRock WiFi 2.4/5/6 GHz Antennas
• - 1 x ARGB Splitter Cable
• - 1 x Thermistor Cable
• - 1 x Screw for M.2 Socket
• - 1 x Standoff for M.2 Socket
• Form Factor - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm
• - 8 Layer PCB
• OS - Microsoft Windows 10 64-bit / 11 64-bit
• Certifications - FCC, CE
• - ErP/EuP ready (ErP/EuP ready power supply is required)
