GA-SBC7300
GA-SBC7300
- 中央處理器(CPU): Built-in Intel | ® | Core I Series i5-7300U Quad core MCP 15W processor | * Do not disassemble the onboard SoC and the heatsinks by yourself to avoid damage to these components.
- 記憶體: 2 x DDR4 SO-DIMM sockets supporting up to 16 GB of system memory | | Support for DDR4 2133 MHz memory module | | (Please refer "Memory Support List" for more information.)
- 顯示功能: 1 x Display port, supporting a maximum resolution of 3840x2160@60 Hz | | 1 x HDMI port, supporting a maximum resolution of 3840x2160@30 Hz | | 1 x LVDS, supporting a maximum resolution of 1920x1200@60 Hz
- 音效: Realtek | ® | ALC255 codec | | High Definition Audio | | 2-channel
- 網路: 1 x Intel i211AT | ® | GbE LAN chips (10/100/1000 Mbit) | | 1 x Intel i219LM
- 擴充槽: 1 x M.2 Socket 1 connector for an Wifi module | | 1 x full size Mini PCIe connector (MSATA_MPCIE) | * The MINI_PCIE connector can also be used as an MSATA connector. | | (The Mini PCIe connector conforms to PCI Express 2.0 standard.)
- 儲存裝置介面: Integrated in the SoC: | | 1 x M.2 connector (Socket 3, M key, type 2280 PCIe x1 SSD support) (M2) | | 2 x SATA 6Gb/s connector | | 1 x MSATA connector (MSATA_MPCIE)
- USB: Integrated in the SoC: | | 4 x USB 3.1 Gen 1 ports on the back panel | | 4 x USB 2.0/1.1 ports available through the internal USB headers
- 內接插座: 1 x DC-In power connector | | 1 x system fan header | | 2 x SATA 6Gb/s connector | | 1 x M.2 Socket 3 connector | | 1 x SATA power connector | | 1 x front panel header | | 4 x USB 2.0/1.1 headers | | 4 x serial port headers | | 4 x serial port power select jumpers | | 1 x GPIO header | | 1 x LVDS header | | 1 x LVDS drive voltage jumper (LCD_VCC) | | 1 x flat panel display header (FPD) | | 1 x flat panel display switch header (MON_SW) | | 1 x speaker header (SPEAKER) | | 1 x speaker control header (SPKR_CTRL) | | 1 x Clear CMOS jumper | | 1 x I2C jumper | | 1 x SMBUS jumper
- 後方面板裝置連接插座: 1 x HDMI port | | 1 x Display port | | 4 x USB 3.1 Gen 1 ports | | 2 x RJ-45 ports | | 1 x audio jacks (Line In, Mic In)
- I/O控制器: Nuvoton NCT6116D
- 硬體監控: System voltage detection | | Temperature detection | | Fan speed detection | | Fan speed control | * Whether the fan speed control function is supported will depend on the cooler you install.
- BIOS: 1 x 128 Mbit flash | | Use of licensed AMI UEFI BIOS | | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- 附加工具程式: Support for Xpress Install | | Support for APP Center | * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications
- 附贈軟體: Norton | ® | Internet Security (OEM version)
- 作業系統: Support for Windows 10 64-bit
- PCB規格: SBC Form Factor; 14.6cm x 10.2cm
- Operating Temperature: 0°C to +60°C
- 備註: Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website. | | Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP SP1/SP2. If drivers are available from the vendors, we will update them on the GIGABYTE website.
