GB-BNi3-N305
GB-BNi3-N305
- 體積尺寸: 163.5 x 116.8 x 28.5 mm | 0.54 L
- 主機板尺寸: 154 x 110 mm
- 處理器: Intel | ® | Core | TM | i3 Processor N305 | CPU 3.0G~3.8G Turbo, 8C/8T Core, 6MB L3 Cache
- 記憶體: 1 x SO-DIMM DDR4 slot | 3200MHz | Max. 32GB
- LAN: 2.5 GbE LAN (Realtek RTL8125)
- Wifi Card: Intel AX101 | Wi-Fi 6 ; 802.11ax ; 2.4 & 5 GHz
- 繪圖晶片: Intel | ® | UHD Graphics 1250
- Audio: Realtek ALC897
- HDMI 解析度(最大值): HDMI 2.1 | Support 4K@60P HDR10
- Mini DP 解析度(最大值): DP 1.4 | support 4K@60P HBR2
- 儲存裝置: 1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) | 1 x M.2 2280 slots for SSD (PCI-e x2)
- 擴充插槽: 1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) | 1 x M.2 2280 slots for SSD (PCI-e x2) | 1 x M.2 2230 slot (PCI-e x1 ; A-E key slot occupied by the Wi-Fi + Bluetooth card)
- 前置 I/O: 1 x Power Button | 1 x USB3.2 Gen2 Type-A | 1 x USB3.2 Gen2 Type-C | 1 x Headphone / Microphone
- 背板 I/O: 2 x HDMI 2.1 | 1 x 2.5 GbE RJ45 | 3 x USB 2.0 Type-A | 1 x USB 3.2 Gen2 Type-A | 1 x DC-In | 1 x DP 1.4 | 1 x Kensington lock slot
- 電源供應: Input: AC 100-240V | Output: DC 19V/4.74A, 90W
- VESA 支援: VESA support | Supports 75 x 75 and 100 x 100 mm
- Support OS: Win11 64 bit
- 環境操作溫度: System Environment Operating Temperature: 0°C to +35°C | System Storage Temperature: -20°C to +60°C
- 體積尺寸: 163.5 x 116.8 x 28.5 mm | 0.54 L
- 主機板尺寸: 154 x 110 mm
- 處理器: Intel | ® | Core | TM | i3 Processor N305 | CPU 3.0G~3.8G Turbo, 8C/8T Core, 6MB L3 Cache
- 記憶體: 1 x SO-DIMM DDR4 slot | 3200MHz | Max. 32GB
- LAN: 2.5 GbE LAN (Realtek RTL8125)
- Wifi Card: Intel AX101 | Wi-Fi 6 ; 802.11ax ; 2.4 & 5 GHz
- 繪圖晶片: Intel | ® | UHD Graphics 1250
- Audio: Realtek ALC897
- HDMI 解析度(最大值): HDMI 2.1 | Support 4K@60P HDR10
- Mini DP 解析度(最大值): DP 1.4 | support 4K@60P HBR2
- 儲存裝置: 1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) | 1 x M.2 2280 slots for SSD (PCI-e x2)
- 擴充插槽: 1 x M.2 2280 slots for SSD (PCI-e x2 or SATA) | 1 x M.2 2280 slots for SSD (PCI-e x2) | 1 x M.2 2230 slot (PCI-e x1 ; A-E key slot occupied by the Wi-Fi + Bluetooth card)
- 前置 I/O: 1 x Power Button | 1 x USB3.2 Gen2 Type-A | 1 x USB3.2 Gen2 Type-C | 1 x Headphone / Microphone
- 背板 I/O: 2 x HDMI 2.1 | 1 x 2.5 GbE RJ45 | 3 x USB 2.0 Type-A | 1 x USB 3.2 Gen2 Type-A | 1 x DC-In | 1 x DP 1.4 | 1 x Kensington lock slot
- 電源供應: Input: AC 100-240V | Output: DC 19V/4.74A, 90W
- VESA 支援: VESA support | Supports 75 x 75 and 100 x 100 mm
- Support OS: Win11 64 bit
- 環境操作溫度: System Environment Operating Temperature: 0°C to +35°C | System Storage Temperature: -20°C to +60°C
